'33 Hot Rod Complete Kit: $20,990

The Factory Five ‘33 Hot Rod complete kit comes with all of the parts you need to build your car except for the engine, transmission, rear-end, wheels, tires and paint.

What You Get

Frame:

Complete jig-welded tube frame. Includes all mounts ready to accept small block Ford, 4.6L, 5.0L Coyote, and Chevy SB and LS engines.

• Includes full width roll bar
• Mounts 3-link, 4-link, or IRS

Body:

Hand laid 3/16” laminate composite body and panels made with vinylester resin.

• Driver and passenger doors with molded door liners
• Trunk with molded trunk liner
• Includes secondary body fasteners assembly.
• Adhesive backed foam weatherstrip
• Door edge trim and fasteners
• Trunk push on rubber bulb seal
• Rubber hood bumpers
• Includes multi-adjustable door hinges with bronze bushings with fasteners

Chassis Aluminum Panels:

Includes 26 CNC cut, pre-formed 6061-T6 aluminum panels for cockpit, trunk, and engine bay.

• 1,200 pre-packaged rivets; 1/8” short and long, 3/16” short and long
• Complete cockpit aluminum
• 1/8” firewall between engine and passenger compartment

Complete Front Suspension:

Unequal length A-arm control arms with in-board coil-over shock suspension. Comes complete with all parts and fasteners.

• KONI™ brand high-performance mono-tube, rod-end shock absorbers
• Coil-over kit for KONI™ dampers including spring hat, threaded seat and black powder coated performance springs
• Adjustable lower control arms with ball joints and fasteners
• Upper tubular control arms with ball joints and fasteners
• Grade-8 mounting hardware

Factory Five Rear Suspension:

Our 3-link rear suspension options include rear axle brackets, fasteners and axle straps to mount your Mustang 8.8” rear solid axle and brakes. Comes with all hardware required for installation.

• 3-Link Suspension
• KONI™ brand high-performance mono-tube, rod-end shock absorbers
• Coil-over kit for KONI™ dampers including spring hat, threaded seat and black powder coated performance springs
• Factory Five tubular upper and rear lower control arms, with polyurethane bushings and fasteners

Or select our 2015 Mustang independent rear suspension option includes:

  • Welded tubular steel IRS frame
  • Upper and lower control arms with bushings, grease fittings, and fasteners, powdercoated gloss black
  • Left and right IRS toe adjustment arms with rod ends and fasteners, powdercoated gloss black
  • KONI coil-over shocks with coil-over kit, springs, and fasteners
  • Right and left CV axles
  • Rear wheel studs
  • IRS e-brake cable adapter
  • Differential mounting components, bushings, and fasteners
  • Driveshaft adapter for manual cast iron center section
Complete Front Brake Kit:

• Custom spindles with fasteners
• Front hubs, fasteners and dust covers
• Front brakes, Ford Mustang 11” front rotors with twin piston PBR calipers, brake pads and fasteners
•Master cylinder (listed in pedal box assembly), stainless braided front brake line with mount clips, banjo bolts and brake line mounting fasteners
• Pre-flared 3/16” brake line and brake line T-adapter
• OEM Ford Mustang emergency brake handle, fasteners and cable

Complete Steering System:

Complete steering system using rear steer manual rack from tie rod ends and fasteners to steering wheel and badges.

• Manual steering rack with inner and outer tie rod ends and fasteners
• Polyurethane steering rack bushing and fasteners
• Nickel plated lower steering shaft
• 14” banjo steering wheel with boss and ceramic FFR center section and fasteners
• Steering system, including flange bearings and fasteners
• Custom Ididit steering column with frame mounts

Complete Fuel System/Parts:

This assembly provides everything from the gas cap to the lines, and is designed to work with carburetors or fuel injection systems. External fuel pump required.

• Fuel tank with mounting hardware, vent, gaskets, pick-up and fuel level sending unit
• Fuel filler neck and fasteners
• Pre-flared fuel lines (1/4” and 5/16”) with unions, barbs, hose clamps and high press flex lines and fasteners
• Aircraft style brushed aluminum fuel cap with gaskets, ground strap, fuel hose to tank with fasteners
• 3/8” line fuel filter, connectors and hose clamps

Complete Cooling System/Parts:

Electric cooling fan and mounting hardware, radiator hoses, and all necessary fasteners.
• Electric cooling fan and mounting kit with connectors
• Aluminum radiator with cap and filler neck
• Built-in transmission cooler in radiator
• Stainless steel radiator hose kit includes adapter kit, fasteners and hose
• Overflow tank with cap, hoses, hose clamps and mounting hardware
• 185-degree thermostat switch and wiring

Engine Accessories:

The ‘33 Hot Rod kit is configured to accommodate the engine of your choice.

• Engine/transmission mounts (select 302/351, 4.6L, 5.0L Coyote, SB and LS Chevy), with fasteners
• Exhaust, with gaskets and fasteners

Driveshaft:

Select from one of seven available driveshafts with fasteners to match the engine/trans of your choice.

• 28 spline driveshaft for T-5, AOD, or Tremec 3550s
• 31 spline driveshaft for Tremec TKO 500 or 600s
• 31 spline driveshaft for 4.6L or 5.0L Coyote engines with T-45s or 3650s
• 31 spline for LS engine with TKO transmission
• 31 spine for SB Chevy with TKO transmission

Gauges, Dash, and Electrical Assembly:

Complete assembly comes with dash buttons, and indicator lights, switches, and horn.

• Custom fit chassis wiring harness
• Ignition switch and FFR key, headlight switch, hi-low beam switch, starter solenoid and horn button
• Dash indicators: green, blue dash lights (LED)
• Wiring harness mounting kit and hardware including fuse panel mount
• Insulated line clip hardware and fasteners and cable ties
• Battery ground strap
• Speedometer sending unit, pigtail, fasteners and speedometer gear
• A complete set of six Autometer
Platinum electronic gauges, with connectors, terminals and installation kit

Includes the following gauges:
• Speedometer
• Tachometer
• Oil Pressure Gauge
• Water Temperature Gauge
• Fuel Level Gauge
• Voltmeter

Complete Interior Accessories:

The ‘33 Hot Rod kit comes with all the interior accessories you need and want. Bucket seats, door latches, rear view mirrors, and more complement the dash and gauges assembly for a full interior.
Check out this full list of standard parts and assemblies:

• Metal framed bucket seats, black vinyl with fasteners
• 5-point Simpson brand harnesses;
3” wide driver and passenger, frame mounted with fasteners
• Complete cockpit carpet set, black all-weather
• Emergency brake boot, black leather
• Interior rear view mirror with fasteners
• 6-gauge electronic Autometer Platinum gauges (see description above in gauge assembly)
• Interior door latches and fasteners
• Leather shifter boot and fasteners
• Rear cockpit trim piece
• Pleated door panels
• Stitched arm rest
• Banjo style steering wheel (listed in steering assembly), with polished aluminum boss and center badge

Exterior Accessories and Lighting:

Along with the goodies on the inside of the car, the ‘33 Hot Rod kit is loaded with the right exterior parts and trim on the outside.

• Polished windscreen, tinted with fasteners; DOT safety glass compliant
• License plate light and bracket with fasteners
• Ceramic FFR badging nose and tail
• Headlamp assemblies, including chrome buckets, LED headlamps, with integral (LED) turn signal, and fasteners
• Red rear LED tail lights
• Lighting is DOT approved

Complete Pedal Box and Components:

The ‘33 Hot Rod kit utilizes the proven Wilwood brand pedal box with fasteners and all the required ancillary parts.
• Wilwood pedal box and mounting hardware
• Master cylinders
• Accelerator pedal, accelerator cable, return spring and ball stud retainer, with fasteners
• Brake line adapters and T-fittings

Assembly Manual:

Bound assembly manual that is full of pictures, diagrams, and CAD drawings.

Fasteners:

More than 1,600 top quality zinc plated, chrome and stainless steel USS, metric and SAE fasteners, numbered and packed individually by assembly.

What You Need

  • Engine/Transmission/Rear End with Rear Brakes
  • Wheels and Tires
  • Paint
  • Battery
  • Fuel pump
